Wide Format Finishing Just Got Easier

  • Increased Acceleration & Cutting Speeds
  • Triple Interchangeable Tool Head
  • Vision Registration System & Camera
  • Energy Efficient 6-Zone Vacuum System
  • Solid Steel Welded Frame

For Sample Making & Short Run Production:


Samples are produced easily for accurate cutting and creasing on a full range of materials including micro flute through triple wall corrugated, honeycomb, foam, chipboard and paperboard.


Full color samples or printed short run jobs can be cut and creased quickly eliminating printing plate cutting and dies.


The Sharpcut is available with a conveyor belt and automatic board loader increasing productivity and efficiency.


  • Corrugated Containers
  • Folding Cartons
  • POPs/Displays
  • Partitions
  • Protective Packaging
  • And much more…

A powerful cutting system for the packaging industry.

Colex is pleased to announce its latest PX series. It is the most versatile digital cutting system on the market today and offers both cutting and creasing for the packaging industry.

“The Sharpcut PX Series takes advanced creasing design to a whole new level.”

Sharpcut’s advanced engineered design:

The PX Series features an advanced tooling, unobstructed table access, laser pointer, powerful vacuum hold-down, low noise operation and built-in safety beam.

Sharpcut’s complete system:

Sharpcut’s Triple Interchangeable Tool Head offers the complete package of automatically identifying the correct tool for all the demands of today’s package workflow.

Versatility, Speed and Price:

The Sharpcut PX Series offers a complete system for the packaging industry including compatibility with all major CAD systems software on the market today.

  • Fixed heavy duty creasing wheel with two interchangeable tool positions for various knives and creasing wheels.
  • Computer selects proper tool for each job.
  • Optional tools including router, foam knife, drag knife, v-knife and plotting pens.
The Colex Sharpcut is a fully integrated hardware and software solution that turns your digital cutting table into a true short-run production system. This powerful solution provides unmatched productivity by intelligently finishing your graphics with the highest accuracy and efficiency. It includes a camera system powered by Colex Cut Center that individually adjusts your cut files to accurately match your printed graphics and read any diameter registration mark, crop mark or square resulting in highly efficient production.


Vision Registration Video

The work surface is divided into six zones for the 67″ x 126″ and 126″ x 64″ models, four zones for the 67″ x 67″ model, and sixteen zones for the 126″ x 126″ model. Each zone has its own vacuum pump controlled by individual electrical “on/off” buttons on the front panel. The power of the pumps is configured for most substrates used in large format printing.

Our cutting table is designed for cutting sheet and rigid materials while delivering clean, smooth edge quality. The gantry is made out of Aerospace aluminum alloy, strong enough to accommodate the optional 3HP Router. The cutting surface of the machine can withstand 1,000+ pounds of pressure.

  • CAD & Graphic Systems Compatible
  • 3D Software
  • 2D Software
  • Packaging Design Software
  • Library of Packaging Software
  • And More…
Colex Cut Center 8 prepare
Working Area67” x 67”67” x126”
Machine Dimensions98” x 90”98” x148”
Tool HeadTriple Interchangeable Tool HeadTriple Interchangeable Tool Head
CameraIndustrial 3.1MpixelIndustrial 3.1Mpixel
Vacuum System4 Zone (5 kWatt)6 Zone (7.5 kWatt)
Rapid Speed50 IPS/76 m/min80 IPS/122 m/min
Acceleration.86 G.86 G
Bridge Clearance4.0”4.0”
Max. Cutting Thickness2.5”2.5”
Recommended Floor Space14' x 14'14' x18'
Machine Weight3,000 lbs3,500 lbs

Sharpcut Tools
